G-ON3
3 Channel, 128GB, WiFi, GPS, Hard Wire
G-ON3-T
3 Channel, 128GB, WiFi, GPS, Hard Wire, External Camera
Specification:
| Audio input | Built-in Microphone |
| Video Compression | H.265 |
| Audio Compression | ADPCM |
| Resolution | Front : QHD (2560 X 1440) / Rear, Interior, Exterior: FHD (1920 X 1080) |
| Frame Rate | All cameras : Max. 30 FPS |
| 3G/4G/Router (Optional) | Connect to withCLOUD™ via 3G/ 4G/ Router telecommunication |
| Wi-Fi (Optional) | Connect to GNET Smart phone application via Wi-fi® dongle |
| G-Sensor | Event recording by External Shock |
| Speaker | Operation Status alarm / Voice guidance |
| External GPS | Synched with Google map, Keep track of location and Speed |
| Angle Of View | Front : 140˚, Interior : 180˚, Rear & Exterior: 140˚ |
| Viewer | Windows XP/7/8/10, Support 32Bit / 64Bit, Synchronizing Google map with PC viewer is supported over Windows7 and explorer 10 as per Google’ s policy. |
| Power | DC 12V – 24V |
| Acceptable current value of the supplied fuse | 3A |
| Operation Temperature | -20℃ ~ 60℃ |
| Humidity | 10~95% |
| Dimension (WxHxD, mm) | Front : 116x56x32, Interior :48x73x26, Rear: 44x38x28 Exterior: 45x45x35 |
Functionality:
The New Cloud Service for GNET Dash Cam Users
withCLOUD™
“withCLOUD” for fleet management system by GNET SYSTEM’s technology.
Unlimited storage capacity beyond the limitation of dash camera memory card.
*This requires an internet connection with data available, fees and charges will apply.
Outstanding Visibility under the Starlight
The STARVIS is back-illuminated pixel technology used in CMOS image sensors for surveillance camera applications. It features a sensitvity of 2000 mV or more per1 um2(color product, when imaging with a 706cd/m2 light source, F5.6 in 1 s accumulation equivalent), and realize high picture quality in the visible light and near infrared light regions.
ADAS
3 Functions for Safe Driving
“ADAS update”
ADAS is a safe driving assistance system for the driver’s safe driving environment
| FVSA Front Vehicle Start Alarm | FCWS Forward Collision Warning System | LDWS Lane Departure Warning System | ||
| The vehicle in front of you is pulling away more than 2 meters, the dash cam let the driver know with the beep sound | If the distance of the vehicle in front of you is reducing rapidly in short time with high speed, the dash cam let driver know with the beep sound and | If you leave the lane while driving, the dash cam let the driver know with beep sound |
TIME LAPSE
Available for Long Parking Records
Time-lapse function automatically applied when entering parking mode.
Time Lapse mode records one frame per second, minimizing the size of the video for a long time to record parking.
Time Lapse mode records one frame per second, minimizing the size of the video for a long time to record parking.
H.265
Video codec(HEVC)
*HEVC(High Efficiency Video Coding)
H.265 compression rate is up to 2 times higher than H.264.
It means that users can use 256GB SD card as 512GB SD card.
REAL HDR
Clear Recording Quality when Driving at Night
Real HDR is installed to remove light blurring when driving at night,
and it shows clear recording quality in various lighting conditions such as backlight and tunnels.
WIDE VIEWING ANGLE
Optimal Viewing Angle without Distortion
Front camera: 140° / Rear camera: 140° / Interior IR camera(driver, passenger): 180° / Option – Exterior IR, IP69K camera: 140°
Excessive angle of view refracts the image, causing effects such as distortion and loss of distance.
The GNET System has an optimal camera angle of 140° and Interior IR with a 180° angle of view without those problems,
the situation of accidents on the side angle is recorded more reliably, and images without distortion of left / right / up / down are provided.
G-NET APP
Smartphone Link via Wi-Fi®
User-friendly GUI
User convenience has been further upgraded
using intuitive icons for anyone to operate conveniently
| User-focused Firmware Upgrade | All the features you need at once! Easy and convenient GNET APP | Customized configuration by APP |
| After accessing the firmware configuration by APP, the latest firmware can be automatically searched for and downloaded. | You can easily set up device registration, real-time video setup, recorded video list, and customer support through the main screen. | Using the Smartphone APP, you can upgrade the firmware and play video as well as configure various settings |
*You can only connect your smartphone with WiFi® dongle connected to the black box
*Disable IOT/WiFi feature when CLOUD is enabled
LBP FUNCTION
For Vehicle Battery Discharge Protection
It is an intelligent Safe Guard function that automatically shuts down recording when the voltage falls below
a specified voltage and cuts off the power to protect the battery of the vehicle.
LBP FUNCTION AUTO SAFE GUARD ( LBP ON / OFF )
Settings can be made directly from the dedicated GNET PC VIEWER, and the vehicle voltage can be checked when checking
the recorded video of the vehicle. You can easily set up wirelessly via GNET APP at the time of smartphone interlocking
| | | |
| HIGH TEMPERATURE TEST PASS | MEMORY CARD AUTOMATIC RECOVERY AND SELF-FORMAT | BUILT-IN VOICE GUIDE AND MICROPHONE |
| G-Net has been passed the high-temperature test. Differs from other brand dash cameras which shut down the power because they can not withstand high temperatures. | Unlike other companies’ black boxes, which require users to format periodically, JDR’s own file system with excellent reliability is applied for convenient use without regular format. | It has a friendly voice guide, high-quality voice recording, and a high-performance microphone, which makes it easier to check the operation and recording conditions while driving. |
| | | |
| SECURITY LED FUNCTION | EXTERNAL GPS | VARIOUS RECORDING MODES |
| It is equipped with intelligent security LED function to prevent crimes that can parking terrorism and theft. With a clear view, it detects movement in parking mode and starts recording automatically. | You can check at a glance the data image received from the GPS while driving. * External GPS is optional (sold separately) | Parking Surveillance / Motion Detection The event recording is automatically recorded for a certain period of time when the impact is detected on the vehicle in various recording modes. |
GNET PC VIEWER
Compitable GNET PC VIEWER
Easily play and check the recorded video with a viewer program for PC
It provides various functions Zoom, partial zoom function, Lane drawing function, set recording frame.
Backup features include AVI file generation, tampering prevention, thumbnails, and interval repetitive searches.
